SDD250 HDPE yeeb nkab thermofusion vuam tshuab
Nws yog hydraulic pob tw fusion welder. Nws yog siv rau pob tw weld yeeb nkab thiab fittings xws li lub luj tshib, tees, wye thiab flange caj dab yam tsis muaj cov khoom siv ntxiv los ntawm kev kho cov clamps 'txoj kab bar.
Nws yog tsim rau vuam yas yeeb nkab thiab fittings ua los ntawm HDPE, PP, PVDF.
Peb qhov kev lag luam muaj xws li hauv qab no,
1. HDPE yeeb nkab taub qab fusion tshuab (vuam ntau yam:9160-3000mm
2. Fitting ua tshuab rau fabricate luj tshib, tee, ntoo khaub lig thiab wyes fittings (vuam ntau yam: 63mm -2000mm)
3. Cov yeeb nkab pom txiav cov yeeb nkab nrog lub kaum sab xis sib txawv (txiav ntau yam: max: 3000mm)
4. Saddle fusion tshuab ua kom txo tee haum
5. Electrofusion tshuab
Luv luv:
Haum rau vuam ntawm cov kav dej yas thiab fittings ua los ntawm PE, PP & PVDF.
Ua los ntawm cov khoom siv aluminium, yooj yim rau nqa thiab thauj.
Nws muaj cov cuab yeej npaj, cua sov phaj, ncej ncej, Hydraulic Unit thiab kev txhawb nqa.
Feature:
1.Removable PTFE coated cua sov phaj nrog cais kub tswj system.
2. Cov cuab yeej hluav taws xob npaj nrog thim rov qab ob lub txiav ntug hniav.
3. Hydraulic unit muab vuam tshuab nrog compressing zog.
4. Ua los ntawm Aluminium, yooj yim rau nqa thiab thauj.
5. Tsawg pib siab ua kom ntseeg tau qhov zoo ntawm cov kav dej me me.
6. Temperature Controller thiab Timer, yooj yim kom paub lub sijhawm thiab kub.
Technology parameter
| Qauv | SDD 250 |
| Vuam Ntau | 90 110 125 140 160 180 200 225 250 hli |
| Cua sov phaj Max.Temperature | 270 degree |
| Temperature Deviation nyob rau saum npoo | Tsawg dua lossis sib npaug li ± 5 degree |
| Ua haujlwm Voltage | 220V, 50/60HZ |
| Tag Nrho Lub Zog | 3.85 KW UA |
| Cua sov phaj fais fab | 2 KW |
| Planning Tool Fais Fab | 1.1 KW TSI |
| Hydraulic Unit Fais Fab | 0.75KW |
| Siab Adjustable Ranges | 0-6.3Mpa |
| Qhov hnyav | 150 kg |
| Pob | 3 lub thawv ntoo |
| Data Logger Chaw nres nkoj | Xaiv tau |
Hydraulic unit
Cov hluav taws xob tsim nyog yuav raug xa mus! mus rau lub rhaub thiab milling cutter los ntawm txoj kev ntawm chav tsev no thiab mus rau lub ntsiab tshuab los ntawm hydraulic siab.
Tshuab hauv kev sim
FAQ
Q: Koj puas yog tuam txhab lag luam lossis chaw tsim khoom?
A: Peb yog Hoobkas.
Q: Koj lub sijhawm xa khoom ntev npaum li cas?
A: Feem ntau nws yog 3-5 hnub yog tias cov tshuab nyob hauv Tshuag. Yog tias lub tshuab ua haujlwm loj lossis lub tshuab tshwj xeeb, nws yuav siv sijhawm li 15 txog 40 hnub
Q: Koj puas tuaj yeem tsim thiab tsim cov tshuab tshwj xeeb raws li cov neeg siv khoom xav tau?
A: Yog, peb muaj peev xwm ua tau zoo, tuaj yeem tsim cov khoom tshiab los ntawm peb tus kheej tag nrho.
Q: Koj cov nqe lus them nqi yog dab tsi?
A: Them nyiaj<=10000USD, 100% in advance. Payment>=10000USD, 30 feem pua T / T ua ntej, tshuav nyiaj li cas ua ntej xa khoom.
Yog tias koj muaj lus nug ntxiv, pls xav tiv tauj peb raws li hauv qab no:
Kev thauj mus los
Los ntawm Express (FedEx, UPS, DHL, TNT, EMS, thiab lwm yam ... )
--- Qhov zoo: ceev (yuav siv li ntawm 7 - 10 hnub hauv kev xa khoom), qhov rooj rau qhov rooj
--- Qhov tsis zoo: kim me ntsis
Los ntawm Kev Thauj Mus Los
--- Qhov zoo: Ceev ceev ( siv sijhawm li 8 - 12 hnub), pheej yig dua li Express me ntsis.
--- Qhov tsis zoo: Koj yuav tsum nqa cov khoom ntawm tshav dav hlau los ntawm koj tus kheej.
Los ntawm Hiav Txwv (Hiav Txwv) Tsheb thauj mus los
--- Qhov zoo: Ntau qhov pheej yig dua li Express lossis Air tsheb thauj mus los.
Disadvantage: qeeb thiab koj yuav tsum nqa cov khoom ntawm koj qhov chaw nres nkoj ntawm koj tus kheej.
